Intel PROSet Adapter Teaming In Server Core and Hyper-V Server 2008 R2

It turns out that creating an Intel adapter team in Server Core, or in this case Hyper-V Server 2008 R2 is actually quite simple.

Reading through the above page plus the PROSetCL.txt file made things seem a bit intimidating.

In reality, the process is actually quite simple. The PROSetCL.exe command is found in: C:\Program Files\Intel\DMIX\CL.

Here is the process assuming that we are in the above directory:

  1. PROSetCL Adapter_Enumerate
    • The NIC’s index number is at the front of each NIC listed.
    • image
  2. IPConfig /all
    • NIC MAC addresses are needed to map which NICs we need to team.
    • On the Intel Modular Server, the NIC’s MAC addresses will be close together for the on board NIC and again close together for the Mezzanine based NICs.
  3. PROSetCL Team_Create 4,2 TEAM1 VMLB
    • Where the numbers “4” and “2” are the index number for each NIC we want in the team.
    • We team one on board NIC and one mezzanine based NIC to allow for switch redundancy.
    • The management and heartbeat team will be ALB configured.
    • The team that we will bind the Hyper-V vSwitch to will be configured for Virtual Machine Load Balancing (VMLB).

Once we ran the above commands we saw:


Note the adapter team shown as TEAM1 will be our management and heartbeat NIC.
